@DEFINE_SCHEME (Define Color Scheme)

This macro can be used to define an 8-series color scheme using Red-Green-Blue values that will be used to color markers/risers. An RGB value can be hex (0xFF0000=red) or decimal (16711680=red).

SYNTAX:

@DEFINE_SCHEME rgb0 rgb1 rgb2 rgb3 rgb4 rgb5 rgb6 rgb7

PARAMETERS:

rgb0...rgb7; specifies a Red-Green-Blue value in hex or decimal format

EXAMPLE:

@DEFINE_SCHEME 0xFF0000 0xFFCC00 0xFF00CC 0xFF0000 0xFFCC00 0xFF00CC 0xFF0000 0xFFCC00

PERSISTENT:

YES

ALSO SEE:

@COLOR_SCHEME
