@MC (Marker Colors for Box Plots)

For Box Plots only, this macro sets the color of a specified series in the chart.

SYNTAX:

@MC nSeries nRed nGreen nBlue

PARAMETERS:

nSeries; Series Number (1...8)

nRed; 0...255 defines the Red portion of RGB color selection.

nGreen; 0...255 defines the Green portion of RGB color selection.

nBlue; 0...255 defines the Blue portion of RGB color selection.

EXAMPLE:

@BP2 @SZ 24 @MC 1 255 0 0 @MC 2 0 255 0 @MC 3 255 255 0 @MC 4 0 0 255

PERSISTENT:

YES

ALSO SEE:

@GCOLOR to change the color of other chart objects.

NOTES:

This macro is for box plot charts only, Use the @MCOLOR macro to change the color of markers and risers in other chart types.
